Design Capabilities

IPC compliance and certified designers

Allegro or Altium DXP Platform

Schematic editor

PCB layout editor

CAM editor

Cross platform compatibility Import/Export (Allegro, Protel & etc.)

Fabrication Capabilities

Multiple materials; Enhanced FR4 standard

BGA pitches down to 0.4mm

Multi-lam to 5 lamination cycles

Laser-direct imaging

Mixed dielectric constructions

54+ layers

Finished PCB thickness to .310"

Bow and twist to .003in/in

Selective (DUT) flatness to 0.001in/in

Hard, soft & immersion gold finish available

Impedance modeling and testing
